8 Zone CFP repeater panel

The 8 Zone CFP repeater panel is part of the Context Plus CFP Conventional Panel (LPCB Approved) range from Context Plus, supplied and supported by SPS. Can be used to repeat the functions of a master Context Plus CFP standard 2-8 zone fire panels at remote parts of site (e.g. all potential fire service entrances). Up to 8 repeaters per CFP master. Includes its own Mains power supply that requires its own standby battery supply. Provides the user with access to all AL1 and AL2 functions. Master/Repeater communication achieved using CFP761 network driver cards (one CFP761 is supplied with the Repeater, an additional CF761 card is required at the master CFP). Communicates over screened two-wire fire resistant cable. Total repeater network cable length should not exceed 1KM. Attractive flush or surface mountable plastic lid and enclosure – no bezel required.

Specifications & features

• Can be used to repeat the functions of a master Context Plus CFP standard 2-8 zone fire panels at remote parts of site (e.g.
• all potential fire service entrances).
• Up to 8 repeaters per CFP master.
• Includes its own Mains power supply that requires its own standby battery supply.
• Provides the user with access to all AL1 and AL2 functions.
• Master/Repeater communication achieved using CFP761 network driver cards (one CFP761 is supplied with the Repeater, an additional CF761 card is required at the master CFP).
• Communicates over screened two-wire fire resistant cable.
• Total repeater network cable length should not exceed 1KM.
• Attractive flush or surface mountable plastic lid and enclosure – no bezel required.
