High temperature heat detector HEAD ONLY (Xpert card Style- )- LPCB APPROVED
The Context Plus Intelligent Addressable High Temperature Heat Detector model 55000-401IMC monitors temperature by using a single thermistor which pro
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The High temperature heat detector HEAD ONLY (Xpert card Style- )- LPCB APPROVED is part of the Analogue Addressable Fire Detectors range from Context Plus, supplied and supported by SPS. The Context Plus Intelligent Addressable High Temperature Heat Detector model 55000-401IMC monitors temperature by using a single thermistor which provides a count output proportional to the external air temperature. This heat detector is classified as an CS device and will report an alarm at 90°C.
Specifications & features
- Operate over the range –20°C to +120°C High temperature CS heat detector which can be installed in a typical ambient temperature of 55°C.
- Unaffected by wind or atmospheric pressure.
- Alarm flag for fast alarm reporting.
- Alarm address for fast location of alarm.
- Patented XPERT Card addressing that provides simple, user friendly and accurate identification of detector location.
- This addressing card simplifies and speeds up installation and commissioning and eliminates addressing errors during maintenance and service.
- XP95 Communication Protocol.
- Easy installation.
- Elegant design.
- Operates using digital communication.
- Has a high immunity from corruption.
