Firefighter Suit (ZR-A002-NE05)
EN 469:2020 three-layer firefighting suit in Nomex/Kevlar twill with PTFE membrane; sizes S-XXL.
Rescue Combi Tool (MDC390N-E)
Battery-powered hydraulic combi-tool for vehicle extrication; 394 mm spread, 185 mm cutter opening, 22.2 kg, IP54.
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
Battery-powered hydraulic combi-tool that unites a cutter and a spreader in a single unit. Especially suited to vehicle extrication, the MDC390N-E cuts, spreads and pulls, with a 394 mm spreading distance, a 185 mm cutter opening and a 54V brushless motor at 700 bar working pressure.
Specifications & features
- Combines cutter and spreader in a single tool — cuts, spreads and pulls
- Especially suitable for vehicle extrication
- Compact and manageable design
- 54V brushless motor
- 70 MPa (700 bar) working pressure
- Cutter rating A6 / B7 / C6 / D7 / E7 to NFPA 1936
- EN 13204 classification BK30/390-H-22
- IP54 protection rating
- CE marked and UL certified compliant to NFPA 1936, 2015 edition
- Battery and charger not included
Technical specification
| Part Number | 150.03624 |
|---|---|
| Spreading Distance | 394 mm |
| Cutter Opening | 185 mm |
| Working Pressure | 70 MPa (700 bar) |
| Cutter Rating (NFPA 1936) | A6 / B7 / C6 / D7 / E7 |
| HSF Highest Spreading Force | 39.7 kN (4 t) |
| LSF Lowest Spreading Force | 29.6 kN (3 t) |
| Motor | 54V brushless |
| Dimensions L×W×H (closed) | 861 × 274 × 241 mm |
| Dimensions L×W×H (open) | 754 × 360 × 241 mm |
| Weight (without battery) | 22.2 kg |
| EN 13204 Classification | BK30/390-H-22 |
| Protection Rating | IP54 |
Approvals & certifications
CE · UL certified compliant to NFPA 1936 (2015 Edition) · EN 13204 · NFPA 1936
Model: MDC390N-E (150.03624)
