SE-G10.2
Deye SE-G10.2 - 10.24kWh 51.2V 200Ah LiFePO4 battery, rack, wall or stack mounted, expandable to 64 units.
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The SE-G10.2 doubles the SE-G5.1 into a single 10.24kWh module (supplied by SPS), which halves the number of packs, cables and BMS links in a large home bank. It holds 200Ah at 51.2V, mounts in a rack, on a wall or stacked, and parallels up to 64 units. Cobalt-free LiFePO4 cells are rated beyond 6000 cycles.
Specifications
- Battery Chemistry: LiFePO4 (cobalt-free)
- Nominal Energy: 10.24 kWh
- Nominal Capacity: 200 Ah
- Nominal Voltage: 51.2 V
- Operating Voltage: 44.8 - 57.6 V
- Scalability: Up to 64 units in parallel
- Cycle Life: 6000+ cycles
- Operating Temperature: -20 to 55 C
- Communication: CAN 2.0 / RS485
- Mounting: Rack, wall or stacked
- Dimensions (W x H x D): 710 x 540 x 133 mm
- Weight: 85 kg
