No Break Resettable Conventional Manual Call Point
Provide a unique ‘plug and play’ concept designed specifically to reduce installation time. Utilise a special terminal block, where all initial instal
Waterproof manual call point – red (surface); for use with range; IP67 with built in isolator
The Context Plus Waterproof manual call point has a highly visible alarm indicator which can be seen from up to 10 metres away. The manual call point
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The Waterproof manual call point – red (surface); for use with range; IP67 with built in isolator is part of the Analogue Addressable Manual Call Points And Pull Stations range from Context Plus, supplied and supported by SPS. The Context Plus Waterproof manual call point has a highly visible alarm indicator which can be seen from up to 10 metres away. The manual call point interrupts the polling cycle for a fast response, when activated. A combined LED indicator and front reset mechanism allows for a simple reset.
Specifications & features
- The address of each Manual Call Point is set at the commissioning stage by means of a seven-segment DIL switch.
- A red alarm LED is provided on the Manual Call Point.
- This LED is controlled independently of the Manual Call Point, by the fire control panel.
- Once activated, the Manual Call Point can be reset by inserting the reset key into the front facing LED, turning clockwise until a positive click and reset occurs.
- The Context Plus waterproof Manual Call Point incorporates a short circuit isolator which will ensure its operation in the event of a short circuit fault on the loop.
- Isolator operation is indicated by a yellow LED.
- Resettable operating element Easy access, front reset mechanism Ergonomic reset key EN 54-11 and EN 54-17 Compliant.
- 170° viewable LED Incorporates a short circuit isolator IP67 rated
