YO3 – Multi-Tone Sounder
The Y03 is a compact, high output, 104dB(A) Multi-tone alarm sounder. It is suitable for fire, security and industrial applications. 230V AC supply Ac
- Genuine, fully-supported equipment
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The YO3 – Multi-Tone Sounder is part of the Accessories range from Context Plus, supplied and supported by SPS. The Y03 is a compact, high output, 104dB(A) Multi-tone alarm sounder. It is suitable for fire, security and industrial applications. 230V AC supply Activated by a relay module 32 alarm tones Frequency 300-2900Hz 90 – 100dB(A) output at 1 meter For indoor or outdoor use EN 54-3.
Specifications & features
- The Y03 is a compact, high output, 104dB(A) alarm sounder powered by 230V AC.
- It is suitable for fire, security and industrial applications.
- The sounder connects into the Alarm system via a compatible relay module such as the Ei128R, Ei128RBU or Ei428.
- When the system goes into alarm, the relay switches powering the sounder.
- The sounder will then emit the tone selected.
- The sounder has a choice of 32 alarm tones UKOOA / PFEER compliant that can be selected using the dip switch (DIP-12N).
- The sound volume can also be manually adjusted through a volume control dial on the circuit board.
