Addressable loop powered red Vantage Compact Beacon c/w shallow base- INTERTEK Approved
The Context Plus red Vantage loop powered Compact beacon c/w shallow base is third-party certified to EN54-23 (VADs) and 17 (Isolators) by Intertek. P
S.P.S — Product
Addressable Combined loop powered red Sounder/Beacon with Deep base- LPCB Approved
• The Context Plus Addressable Combined loop powered red Sounder/Beacon with Deep base is third-party certified to EN54-3 (Sounders), EN54-23 (VADs) a
- Genuine, fully-supported equipment
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The Addressable Combined loop powered red Sounder/Beacon with Deep base- LPCB Approved is part of the Analogue Addressable Audio Visual & Voice Alarms range from Context Plus, supplied and supported by SPS. • The Context Plus Addressable Combined loop powered red Sounder/Beacon with Deep base is third-party certified to EN54-3 (Sounders), EN54-23 (VADs) and 17 (Isolators) by the LPCB. • Provides 'W-2.4-8.2' light distribution when wall mounted (min 0.4 lux over a 2.4m x8.2m cuboid area). • Impressive 103dB(A) sound output @ 1m. • Onboard short-circuit loop isolator. • 550µA quiescent current. • 14.5mA alarm current @24V DC (VAD lit, sounder on max). • Group addressing facility allows multiple devices to be operated simultaneously. • 7 selectable volume levels and up to 15 selectable tone pairs. • IP33C (Type B) rated.
Specifications & features
- The Context Plus Addressable Combined loop powered red Sounder/Beacon with Deep base is third-party certified to EN54-3 (Sounders), EN54-23 (VADs) and 17 (Isolators) by the LPCB.
- Provides 'W-2.4-8.2' light distribution when wall mounted (min 0.4 lux over a 2.4m x8.2m cuboid area).
- Impressive 103dB(A) sound output @ 1m.
- Onboard short-circuit loop isolator.
- 550µA quiescent current.
- 14.5mA alarm current @24V DC (VAD lit, sounder on max).
- Group addressing facility allows multiple devices to be operated simultaneously.
- 7 selectable volume levels and up to 15 selectable tone pairs.
- IP33C (Type B) rated.
