Addressable loop powered red Sounder with deep base IP55

REF. SPS-0220 Official equipment
Addressable loop powered red Sounder with deep base IP55 image 1

The Context Plus red Addressable loop powered sounder with Deep base is compliant with EN54-3 (Sounders) and 17 (Isolators). Impressive 103dB(A) sound

Ask on WhatsApp
  • Genuine equipment we support ourselves
  • Technical guidance from our engineers
  • Add several products, request one quote
Datasheet Contextplus addressable sounders beacons Jan18 Manufacturer
Overview

Product Details

The Addressable loop powered red Sounder with deep base IP55 is part of the Analogue Addressable Audio Visual & Voice Alarms range from Context Plus, supplied and supported by SPS. The Context Plus red Addressable loop powered sounder with Deep base is compliant with EN54-3 (Sounders) and 17 (Isolators). Impressive 103dB(A) sound output @ 1m. Onboard short-circuit loop isolator. 550µA quiescent current. 5mA alarm current @24V DC (sounder on max). Group addressing facility allows multiple devices to be operated simultaneously. 7 selectable volume levels and up to 15 selectable tone pairs. IP55 rated.

Specifications & features

  • The Context Plus red Addressable loop powered sounder with Deep base is compliant with EN54-3 (Sounders) and 17 (Isolators).
  • Impressive 103dB(A) sound output @ 1m.
  • Onboard short-circuit loop isolator.
  • 550µA quiescent current.
  • 5mA alarm current @24V DC (sounder on max).
  • Group addressing facility allows multiple devices to be operated simultaneously.
  • 7 selectable volume levels and up to 15 selectable tone pairs.
