Overview
Product Details
The Manifold Check Valves ( 1″ ,1-1/2″ ,2-1/2″ ,4″ ) – UL Listed is part of the Clean Agent Fire Extinguishing System Cylinders & Accessories range from Context Plus, supplied and supported by SPS. Check valves are used when two or more agent storage cylinders are manifolded together with one common discharge piping configuration. Their purpose is to prevent the loss of agent in the event that any of the agent storage cylinders are not connected to the manifold at time of system discharge and to prevent back flow of agent into other cylinders attached to the manifold.
Specifications & features
- Check valves are used when two or more agent storage cylinders are manifolded together with one common discharge piping configuration.
- Their purpose is to prevent the loss of agent in the event that any of the agent storage cylinders are not connected to the manifold at time of system discharge and to prevent back flow of agent into other cylinders attached to the manifold.
- All components of the check valves are constructed from brass for durability and protection against corrosion.
- The metal to metal sealing area of the disc and seat is precision lapped, providing a very tight shut-off of both gas and liquid.
- Part Number Description Valve Size CP 60261 Check Valve 1″ CP 60262 Check Valve 1-1/2″ CP 60263 Check Valve 2-1/2″ CP 60264 Check Valve 4″
