Red Fire telephone EVC outstation c/w handset (push to open version)

The Red Fire telephone EVC outstation c/w handset (push to open version) is part of the Fire Telephone & Disabled Refuge Systems range from Context Plus, supplied and supported by SPS. The EVC301PRO is an attractive Type A fire telephone outstation c/w telephone-style handset for use with the Sigtel Fire Telephone system of Context Plus. Supplied in a durable 'push-to-open' red steel case. Ideal for use in fire telephone systems. Allows stewards and fire marshals to communicate with a SigTEL Master Controller (and vice versa). Facilitates reliable two-way communication in a fire emergency between a permanently manned control room and key points of a site. True duplex speech. Can be surface mounted using a T-BEZ302 bezel. Meets and exceeds the requirements of BS 5839-9 when correctly installed.

Specifications & features

• Approvals/certifications: Facilitates compliance with BS5839-9 when correctly installed.
• Supply/operating voltage: 11V DC derived from a compatible SigTEL Master Controller (drops to 6 V DC when in use).
• Quiescent current: 1mA Activation current: 25mA (current draw when handset is in use).
• Open collector outputs: None.
• Indicators: When the operator in the control room calls the outstation, a pulsed ringing tone sounds at the outstation.
• Controls: 'Push to Open' catch.
• Telephone-style handset (lift to answer or make a call).
• Expansion connections: None.
• Product dimensions (mm): 202 W x 278 H x 100 D mm.
• Construction & finish: Red steel (RAL 3000).
• IP Rating: IP20.
• Weight: 3 kg.
• Operating conditions/temperature: -5ºC to +40ºC.
• Max relative humidity: 95%.
• Notes: Microphone frequency response 250 Hz to 5 kHz ±3 dB;
• Loudspeaker frequency response 250 Hz to 4 kHz ±3 dB.
