Ten zone repeater panel

The Ten zone repeater panel is part of the Context Plus FP Range Conventional Panels - 1 to 14 Zone range from Context Plus, supplied and supported by SPS. The FF396-2 is a 10 zone Repeater Panel that displays the zone(s) from which a fire condition has been initiated by illumination of a steady red light(s). When the alarm sounders are silenced at the main control panel the zone light(s) on the Repeater Panel are extinguished, and the Fault light is illuminated. This state is maintained until the main control panel is Reset or other Zones are triggered. The Fault light is also illuminated in the case of a Lamp Test or fault condition at the main control panel.

Specifications & features

• The FF396-2 is a 10 zone Repeater Panel that displays the zone(s) from which a fire condition has been initiated by illumination of a steady red light(s).
• When the alarm sounders are silenced at the main control panel the zone light(s) on the Repeater Panel are extinguished, and the Fault light is illuminated.
• This state is maintained until the main control panel is Reset or other Zones are triggered.
• The Fault light is also illuminated in the case of a Lamp Test or fault condition at the main control panel.
• The nature of the fault is not indicated and must be determined at the Main Control Panel.
• When mains power to the whole Fire Alarm system is correct then a green Mains On light is illuminated.
• The Repeater Panel has an integral fault sounder which mimics the Main Control Panel fault sounder and thus can be muted from the main control panel.
• There is provision for locally testing the Repeater panel lights & fault buzzer via the "Test Lamps" button on the front of the Panel.
• The FF396-2 Repeater Panel is designed solely for use with the Context Plus Conventional FP range of fire control panels.
• It consists of the wall mounted Repeater Panel which contains a 10 zone receiver circuit board and a Transmitter Board which is mounted in the main fire control panel unit.
