Siamese / Breeching Connection
Breeching inlet / fire department connection to BS 5041 Part 3:1975, 4" and 6", two-way or four-way; LPCB approved version available.
Landing Valves
DN65 brass oblique landing valve to BS 5041 Part 1; 2.5" BSP inlet, 2.5" BS 336 outlet, 16 bar working pressure.
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
Globe-pattern oblique hydrant landing valve in brass, manufactured to comply with BS 5041 Part 1 with a delivery hose connection. Classified as low pressure and intended for wet risers permanently charged from a pressurised water supply.
Specifications & features
- Globe pattern hydrant valve manufactured to comply with BS 5041 Part 1
- Brass construction
- Delivery hose connection to BS 336
- Classified under low pressure
- Suitable for internal or external fire hydrant systems on wet risers
- For use with a permanently charged, pressurised water supply
Technical specification
| Size | DN65 |
|---|---|
| Material | Brass |
| Inlet | 2.5" BSP |
| Outlet | 2.5" BS 336 |
| Working Pressure | 16 bar |
| Testing Pressure | 24 bar |
| Measurements | 37 × 37 × 18 cm / 4 pcs |
| Gross Weight | 16 kg |
Approvals & certifications
BS 5041 Part 1 · British Standards
Model: Oblique Landing Valve (BS Standard)
