Attack Hose DUZ-Series (UL)
UL listed nitrile rubber attack hose, 1½" to 3", meets or exceeds UL 19 / BS 6391 / NFPA 1961.
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
UL listed attack hose with nitrile rubber as both cover and liner over a polyester reinforcement. The ribbed cover resists abrasion while the smooth liner keeps friction loss to a minimum, and the hose stays flexible enough to deploy and roll up into a compact coil.
Specifications & features
- Ribbed cover with great abrasion resistance, smooth liner for minimum friction loss
- Nitrile rubber cover and liner over polyester reinforcement
- Resistant to weather, UV, oxidation and most chemicals or petroleum products
- Flexible to deploy and roll up, compact coil for storage
- Temperature range -4 °F to 158 °F (-20 °C to 70 °C)
- Applicable to brass/aluminium NST/NPSH threaded couplings, other types on request
- Standard lengths 50', 100', 200', up to 660'
- Available with customised colour, couplings and marking
- Meets or exceeds UL 19 / BS 6391 / NFPA 1961
- Within an ISO-9001 quality management system
Technical specification
UL/ULC certified sizes shown. BSI certified variants (218 psi / 15 bar working, 654 psi / 45 bar burst) are listed in the attached datasheet.
| Nominal Size | Working Pressure | Burst Pressure | Average Weight | Wall Thickness |
|---|---|---|---|---|
| 1-1/2" (38 mm) | 250, 300 psi (17, 21 bar) | 750, 900 psi (51, 63 bar) | 0.21 lb/ft (0.31 kg/m) | 0.083 in (2.1 mm) |
| 1-3/4" (45 mm) | 250, 300 psi (17, 21 bar) | 750, 900 psi (51, 63 bar) | 0.24 lb/ft (0.36 kg/m) | 0.114 in (2.9 mm) |
| 2" (52 mm) | 250, 300 psi (17, 21 bar) | 750, 900 psi (51, 63 bar) | 0.30 lb/ft (0.45 kg/m) | 0.118 in (3.0 mm) |
| 2-1/2" (65 mm) | 250, 300 psi (17, 21 bar) | 750, 900 psi (51, 63 bar) | 0.39 lb/ft (0.58 kg/m) | 0.118 in (3.0 mm) |
| 3" (75 mm) | 250, 300 psi (17, 21 bar) | 750, 900 psi (51, 63 bar) | 0.58 lb/ft (0.87 kg/m) | 0.118 in (3.0 mm) |
Approvals & certifications
UL · ULC · BSI · UL 19 · BS 6391 · NFPA 1961 · ISO-9001
Model: DUZ (DURAMASTER)
