SUN-12K-SG04LP3-EU
Deye SUN-12K-SG04LP3-EU - 12kW three-phase 48V hybrid inverter with 240A battery charging and 24kW PV input.
SUN-8K-SG05LP1-EU-SM2-P
Deye SUN-8K-SG05LP1-EU-SM2-P - 8kW single-phase 48V hybrid inverter with 190A battery charging and 97.6% peak efficiency.
- Genuine equipment we support ourselves
- Technical guidance from our engineers
- Add several products, request one quote
Overview
Product Details
The SUN-8K-SG05LP1-EU-SM2-P is Deye's 8kW single-phase hybrid inverter (supplied by SPS), sized for larger villas and small shops running on a 48V lithium bank. Two MPPT trackers take up to 16kW of PV, battery current reaches 190A, and peak efficiency is 97.6%. Up to 16 units parallel for on-grid and off-grid operation.
Specifications
- Rated Output Power: 8000 W
- Max Apparent Power: 8800 VA
- Phase: Single phase, 220/230 Vac
- Battery Voltage Range: 40-60 V
- Max Charging / Discharging Current: 190 A
- Max PV Access Power: 16000 W
- Max PV Input Power: 12800 W
- Max PV Input Voltage: 500 V
- MPPT Voltage Range: 150-425 V (2 MPPT)
- Max Efficiency: 97.6%
- Parallel Capability: Up to 16 units
- Protection Rating: IP65
